Snap plug,plug gauges,

What's the details of Plug Gauge?

Specification Φ5.2*100L
Basic Material GCr15
Heat Treatment HRC60-65
Total Length 100mm
Go Side Length 20mm
No Go Side Length 13mm
Go Side and No Go Side Diameter 5.2mm
Unspecified surface chamfering 1*45°
Unspecified Tolerance grade conforms to GB/T1804-2000-f
Unspecified Form and Location Tolerance Conforms to GB/T1184-1996-H
Certificate ISO9001
